EI/UI/EE Lamination Stacking Machine - since 1972
Original manufacturer from Taiwan HT5C U-trust to EI-250/UI210
High Reliability / Accuracy / Durability / Efficiency Machine
How to use the automatic machine?
Easy operation.
EI-35 Stacking Machine
Only 6 seconds
EI-66.7 Stacking Machine
Only 10 seconds
EI-85.8 Stacking Machine
Only 23 seconds.
How to operate the automatic machine?
How to operate the manual machine?
Manual instruction :
Machine operation procedure - Only 3 steps. Exp.: EI-57 Machine
-1. Put the E lamination 1 pce each on the bobbin before place in the machine.
-2. Start to use the machine.
-3. The transformer is complete in a short time.
-4. The EI Lamination core Qty on the Feeding EI slip Tower?
If your EI Lamination is big size, We suggest always remaining an extra 1/3 - 1/2 Qty of E & I Lamination core material on the E & I storage Feeding slip tower. These Lamination's weight will be helpful for pressing and fixing the bottom single Lamination position to stack into the Bobbin smoothly, without the E or I Lamination shaking while stacking into the Bobbin.
For example, 1 unit completed transformer is required 30 pcs EI Lamination core qty.
Please put the min. 60 pcs EI Lamination core qty on the EI storage feeding slip towers before stacking. 1 UNIT TRANSFORMER STACKING is required for the min. 2 UNITS transformer EI Lamination Core material on the feeding slip towers.
EI Q'TY
